LASER PIPE CUTTING MACHINE
Machine Features
Fiber laser technology delivers narrower cutting kerf, lower material loss, high positioning precision and faster processing speed.
The complete system features high integration, outstanding stability and cutting-edge technology.
Low maintenance cost and energy consumption.
Closed-loop control with high-energy pulse power.
Widely applied in industries including 3C electronic products, sheet metal cutting, aerospace, automobile manufacturing, shipbuilding, instrumentation electronics, mechanical & electrical products, lighting equipment, household appliances and precision parts.
设备型号 / MODE No | WHJL12025A | WHJL8025 | WHJL6025 | WHJL4020 |
激光功率 / Laser Power | 20000W-10000W | 15000W-8000W | 12000W-6000W | 10000W-3000W |
加工幅面 / Working Range | 12000x2500mm | 8000x2500mm | 6000x2500mm | 4000x2000mm |
Y轴行程 / Y Axis track | 12000mm | 8200mm | 6200mm | 4200mm |
X轴行程 / X Axis track | 2600mm | 2600mm | 2600mm | 2600mm |
Z轴行程 / Z Axis track | 150mm | 150mm | 150mm | 150mm |
X,Y轴重复定位精度 / X, Y Axis accuracy | 0.03mm | 0.03mm | 0.03mm | 0.02mm |
X,Y轴最大加速度 / X, Y Axis max. acceleration | 1.0G | 1.0G | 1.0G | 1.0G |
最大空移速度 / Max idling Speed | 150m/min | 150m/min | 150m/min | 150m/min |
工作台最大载重 / Max. load of worktable | 15T | 10T | 7.5T | 2.0T |
整机重量 / Net Weight | 23T | 22T | 18T | 10T |
整机外形尺寸(长X宽X高) / Dimension (LxWxH) | 27500x4100x2300mm | 19000x4100x2260mm | 14900x4100x2260mm | 11500x3770x2200mm |
